1.Introduction
MSA Ultima XE SO2 gas detector 10161693 0-100PPM 3-wire belt relay
LED belt Calibration Certificate Model: A-ULTIMAXXPE71B3S2000030C
2.Main Characteristics
Detection object: Flame
Response spectrum range: 4.3μm, 5.0μm
Detection method: Real-time sampling of optical path
The longest detection distance can reach 50 meters
Using high-speed, low-consumption and high-performance 32-bit data
processing chip
Excellent resistance to radio frequency and electromagnetic
interference
Perfect patent algorithm, fast response, high stability, strong
anti-false alarm ability
Detection angle of 90°
The longest detection distance can reach 50 meters
Multi-level sensitivity settings to meet the needs of different
occasions
Magnetic bar adjusts sensitivity, no need opening the cover on site
Explosion-proof design, suitable for hazardous areas in many types
of industrial sites
3.Technical Parameters
| Spectral response | FD10-UV: 185~260nm |
| FD10-IR2: 4.3μm, 5.0μm |
FD10-IR3: 3.8μm, 4.3μm, 5.0μm FD10-UVIR2: 185~260nm, 4.3μm, 5.0μm |
| Detection method | Real-time sampling of optical path |
| Display | LED lights |
| Status indication | Green LED flashes to indicate normal operation (the number of
flashes every 3 seconds represents the sensitivity level) |
| Red LED always lights to indicate an alarm |
| Operation method | Magnetic bar, adjust sensitivity (4 levels) |
| Signal output | 4-20mA analog |
| Passive relays (for fault and alarm) |
| Ex grade | ExdⅡC T6 Gb/ Ex tD A21 |
| Ingress protection | IP66 |
| Input power | DC24V±6V |
| Working current | ≤30mA (DC24V) |
| Installation method | Wall mounted or lifting or holding-pipe |
| Response time | FD10-IR2: ≤10s
FD10-IR3: ≤20s
FD10-UVIR2: ≤10s
FD10-UV: ≤5s |
Detection distance
(N-heptane fire) | FD10-UV: 30m, 0.3m×0.3m N-heptane fire |
| FD10-IR2: 50m, 0.3m×0.3m N-heptane fire |
| RD10-IR3: 50m, 0.3m×0.3m N-heptane fire |
| FD10-UVIR2: 50m, 0.3m×0.3m N-heptane fire |
| Working temperature | FD10-UV: -20~60℃ |
| FD10-IR2: -25~70℃ |
| FD10-IR3: -25~70℃ |
| FD10-UVIR2: -20~60℃ |
| Field of view | FD10-UV: 120° |
| FD10-IR2: 100° |
| FD10-IR3: 100° |
| FD10-UVIR2: 100°(IR) / 120° (UV) |
| Weight | 1.5±0.2kg |
| Housing material | Copper-free cast aluminum |
| Cable entry screw | NPT1/2 |
| Working humidity | ≤95%RH (no condensation) |
