flammable toxic gas multiple gases portable gas detector for
industrial application
Description:
BX616 is a multiple gas detector which can detect the combustible
gases, O2, CO and H2S gases in the air. Its functional and watertight design (IP 66)
incorporates a Bump proof, rubberized enclosure to meet the
toughest requirement of harsh environment like underground tunnels,
mines etc.
The detector is widely used in petroleum , chemical , environmental
protection , metallurgy , etc. which is necessary to safely monitor
toxic and harmful , and explosion industries . The detector can
effectively predict of dangerous gas concentration and alarm ,
ensure the safety of the workers is not threatened , and the
production equipment is not damaged.
Features:
- Intrinsically safe design
- 100,000 records storage capacity including peak value
- Calibration point adjustable
- Adjustable 2-level alarm levels; STEL and TWA alarm
- Audible, visual and vibration alarm
- Self-protection design for combustible gas sensor
- Battery low voltage alert function
- Data uploading
- Self-test when power on
- Self-diagnostic and auto-correction function.
Technical parameters:
| Detection method | Diffuse naturally |
| Detecting gas | See attached table on the last page |
| I.S Parameters | Um=7.48V Ui=4.2V Ii= 1.08 A |
| Battery | DC3.7V 1800mAh Lithium battery (Model Number: FRT-FB101S02,
Um=7.48V) |
| Response time | T90＜30s |
| Indication error | ±5% FS |
| Working condition | Temperature: -20℃～50℃ Humidity: ＜95%RH (no condensation) |
| Charging time | ≤ 6 hours |
| Battery working time | ≥ 8 hours (no alarm status) |
| IP Rating | IP66 |
| Ex Markings | Ex ia IIC T4 Ga Ex ib db IIC T4 Gb |
| Certificate | TÜV 17 ATEX 8115 X IECEx TUR 17.0048X |
| Dimension | L*W*H 120mm×68mm×30mm |
| Weight | About 220g |
Product Details:
Company profile:
Henan Weiguo Intelligent Technology Co., LTD., founded in 2015, is
an important subsidiary of Hanwei Electronics Group Corporation
(Stock no.:300007) in the field of intelligent healthy, safe home
and IoT business. Henan Weiguo Intelligent Technology Co., LTD.,
relying on the core sensor technology, focuses on gas and smoke
alarm, air quality monitor, alcohol tester and firefighting
products. Based on introduction of featured technology from both
Hanwei Electronics Group Corporation and abroad, Henan Weiguo
intelligent Technology Co., LTD., has developed into an innovative
company with the collection of design, R&D development,
production, sales and service. We will always be committed to
becoming the leader in intelligent hardware, providing safe,
healthy, environmentally friendly and intelligent working and
living environment for families and users all over the world.
