| Detector and lens |
| Resolution | 320×256 |
| Pixel Pitch | 30μm |
| NETD | ≤15mK@25℃ |
| Spectral Range | 3.2~3.5um |
| Lens | Standard:24° × 19° |
| Focus | Motorized, manual/auto |
| Display Mode |
| IR Image | Full-color IR Imaging |
| Visible Image | Full-color Visible Imaging |
| Image Fusion | Double band Fusion Mode(DB-Fusion TM): Stack the IR image with
detailed visible image info so that IR radiation distribution and
visible outline info are displayed at the same time |
| Picture in Picture | A movable and size-alterable IR image on top of visible image |
| Storage (Playback) | View thumbnail/full picture on device; Edit measurement/color
palette/imaging mode on device |
| Display |
| Screen | 5”LCD touch screen with 1024×600 resolution |
| Objective | 0.39”OLED with 1024×600 resolution |
| Visible Camera | CMOS,auto focus, equipped with one supplement light source |
| Color Template | 10 types + 1 customizable |
| Zoom | 10X digital continuous zoom |
| Image Adjustment | Manual/auto adjustment of brightness and contrast |
| Image Enhancement | Gas Visualization Enhancement Mode(GVETM) |
| Applicable Gas | Methane, ethane, propane, butane, ethylene, propylene, benzene,
ethanol, ethylbenzene, heptane, hexane, isoprene, methanol, MEK,
MIBK, octane, pentane, 1-pentene, toluene, xylene |
| Temperature Detection |
| Detection Range | -40℃～+350℃ |
| Accuracy | ±2℃ or ±2% (maximum of absolute value) |
| Temperature Analysis | 10 points Analysis |
| 10+10 area(10 rectangle, 10 circle) analysis, including
min/max/average |
| Linear Analysis |
| Isothermal Analysis |
| Temperature Difference Analysis |
| Auto max/min temperature detection: auto min/max temp label on full
screen/area/line |
| Temperature Alarm | Coloration Alarm(Isotherm): higher or lower than designated
temperature level, or in between designated levels Measurement Alarm: Audio/visual alarm (higher or lower than
designated temperature level) |
| Measurement Correction | Emissivity(0.01 to 1.0,or chosen from the material emissivity
list), reflective temperature, relative humidity, atmosphere
temperature, object distance, external IR window compensation |
| File Storage |
| Storage Media | Removable TF card 32G, class 10 or higher recommended |
| Image Format | Standard JPEG, including digital image and full radiation detection
data |
| Image Storage Mode | Storage both IR and visible image in the same JPEG file |
| Image Comment | • Audio: 60 second, stored with images • Text: Chosen among the preset templates |
| Radiation IR Video (with RAW data) | Real-time radiation video record, into TF card |
| Non-radiation IR Video | H.264,into TF card |
| Visible Video Record | H.264,into TF card |
| Timed Photo | 3 sec~24hr |
| Port |
| Video Output | HDMI |
| Port | USB and WLAN, image, video and audio can be transferred to computer |
| Others |
| Setting | Date, time, temperature unit, language |
| Laser Indicator | 2nd level, 1mW/635nm red |
| Power Source |
| Battery | lithium battery, capable of continuous working >3hr under 25℃
normal use condition |
| External Power Source | 12V adaptor |
| Startup Time | About 7 min under normal temperature |
| Power Management | Auto shut-down/sleep, can be set in between “never”, “5 mins”, “10
mins”, “30mins” |
| Environmental Parameter |
| Working Temperature | -20℃～+50℃ |
| Storage Temperature | -30℃～+60℃ |
| Working Humidity | ≤95% |
| Ingress Protection | IP54 |
| Shock Test | 30g, duration 11ms |
| Vibration Test | Sine wave 5Hz~55Hz~5Hz, amplitude 0.19mm |
| Appearance |
| Weight | ≤2.8kg |
| Size | ≤310×175×150mm (standard lens included) |
| Tripod | Standard,1/4” |
