indoor ambient monitoring CO2 PM2.5humidity temperature air quality
monitor for home office hospital school
Descriptions:
AM100 series is a compact indoor ambience monitoring sensor for
measurement of temperature, humidity, light, CO2 concentration, TVOC, barometric pressure and motion. These data
will be shown on the E-ink screen in real-time, which allow to
quantify the indoor environment and comfort. AM100 series is widely
used for offices, stores, classrooms, hospitals, etc.
Features:
- View data remotely by APP through Lorawan.
- historical data can be exported through the App.
- High-precision sensors ensure data consistency.
- Integrated with multiple sensors like humidity, temperature, CO2, light, barometric pressure, etc.
- Visual display via E-ink screen
Technical Specifications:
| Model | AM100 Series |
| Wireless Transmission |
| Technology | LoRaWAN® |
| Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923 |
| Tx Power | 16dBm(868)/20dBm(915)/19dBm(470) |
| Sensitivity | -137dBm @300bps |
| Mode | OTAA/ABP Class A |
| Sensors |
| Temperature |
| Range | -20°C to + 70°C |
| Accuracy | 0°C to + 70°C (+/- 0.3°C), -20°C to 0°C (+/- 0.6°C) |
| Resolution | 0.1°C |
| Humidity |
| Range | 0% to 100% RH |
| Accuracy | 10% to 90% RH (+/- 3%), below 10% and above 90% RH (+/- 5%) |
| Resolution | 0.5% RH |
| PIR |
| Detection Area | 94 ° Horizontal, 82 ° Vertical |
| Detection Distance | 5 m |
| Output Range | 0-65535 |
| Light |
| Range | 60000 lux (Visible + IR, IR) |
| Accuracy | ±30% |
| Carbon Dioxide (CO2) |
| Range | — | 400 - 5000 ppm |
| Accuracy | — | ± (30 ppm or +± 3 % of reading) |
| Resolution | — | 1 ppm |
| TVOC |
| Range | — | 0 - 60000 ppb |
| Accuracy | — | ±15 % |
| Resolution | — | 1 ppb |
| Long-term Stability | — | 1.3 % accuracy drift per year |
| Barometric Pressure |
| Range | — | 300 - 1100 hPa (-40°C - 85°C) |
| Accuracy | — | ±1 hPa |
| Resolution | — | 0.1 hPa |
| Display & Configuration |
| Display | 2.13-inch Black & White E-Ink Screen |
| Configuration | 1. Mobile App via NFC 2. PC software via NFC or USB Type-C port |
| Physical Characteristics |
| Power Supply | 2 × 1.5V AA Alkaline Batteries or Type-C Port |
Battery Life (10 min interval) | Around 1.5 year | Around 1 year |
| Operating Temperature | 0°C to +45°C |
| Relative Humidity | 0% to 100% (non-condensing) |
| Ingress Protection | IP30 |
| Dimension | 105 × 70.4 × 21.2 mm (4.1 × 2.8 × 0.8 in) |
| Installation | Wall Mounting |
| Approvals |
| Regulatory | CE, FCC, RoHS, LoRaWAN® Certified |
| EMC | EN 55032, EN 55035 |
| EMS | IEC 61000-4-2 Level 3 IEC 61000-4-3 Level 2 IEC 61000-4-4 Level 4 IEC 61000-4-5 Level 3 IEC 61000-4-6 Level 3 IEC 61000-4-8 Level 4 |
| Radio Frequency | FCC Part 15B, FCC Part 15.247, EN 300 330,EN 301 489-1/3, EN 300 220-1/2 |
| Safety | EN62368-1 |
Test under laboratory conditions and for guideline purposes only.
